1600°C Heat-Resistant Alumina Fiber Insulation Blanket

Product Description:

1600C High-Temperature Alumina Fiber Blanket is produced using polycrystalline alumina fibers manufactured through a sol-gel method and further processed with advanced needle-punching technology. Composed of alumina and silica, the fibers feature a dense internal structure and stable crystalline phases. The needle-puncing process greatly enhances fiber entanglement, resulting in a blanket with high tensile strength, excellent high-temperature thermal stability, strong chemical corrosion resistance, low thermal shrinkage, low thermal conductivity, and minimal slag ball content. Capable of continuous use at temperatures up to 1600°C, the product offers outstanding dimensional stability and superior insulation performance under extreme heat, making it ideal for long-term application in demanding high-temperature environments.



Product Features:

Excellent high-temperature resistance and thermal stability

Low heat accumulation, low thermal conductivity, and minimal slag ball content

Outstanding tensile strength and thermal-state strength

Superior corrosion resistance, particularly to alkali metals

Good resistance to delamination and high surface smoothness

High thermal reflectivity



Product Applications:

Refractory and thermal insulation linings for industrial kilns and furnaces

High-temperature insulation equipment and pipelines

High-temperature sealing gaskets

High-temperature filtration media

Substrate material for automotive three-way catalytic converters

Aerogel thermal insulation composites

Raw material for modules and folded blocks



Product Technical Parameters:

Item		Test Standard	ALWOOL-72
Chemical Composition Al₂O₃:SiO₂(%)		Chemical Analysis	72:28
Mineral Structure		XRD	δ−Al₂O₃ ​/γ−Al₂O₃ /Mullite
Classification Temperature (°C)		GB/T 3003-2017	1600
Shot Content(≥45um)(%)		GB/T 5480-2017	0-2
Loss on Ignition (%)		GB/T 32179-2015	0.1
Fiber Density (g/cm³)		GB/T 5071-2013	3.1
Average Fiber Diameter (μm)		GB/T 5480-2017	5.5-7.5
Specific Heat Capacity (J/kg·K)		GB/T 19466.4-2016	1.17×10³-1.21×10³
Linear Shrinkage (%)	1400°C×24h	GB/T 17911	≤1
	1600°C×24h		≤1
Thermal Conductivity (W/m·K)	600°C	GB/T 17911	B.D.=96kg/m³ 0.079 0.150 0.215	B.D.=128kg/m³ 0.082 0.152 0.210	B.D.=150kg/m³ 0.070 0.118 0.160
	1000°C
	1200°C
Tensile Strength (kPa)		GB/T 17911	B.D.=96kg/m3 ≥50	B.D.=128kg/m3 ≥70	B.D.=150kg/m3 ≥95

Product Specifications:

Thickness (mm)	Bulk Density (kg/m³)			Width (mm)	Length (m)
	96	128	150
3mm	√	-	-	610/1220	7.2/14.4
6/7.5/10/12.5mm	√	√	√	610/1220	7.2/14.4
20mm	√	√	-	610/1220	3.6/7.2
25mm	√	√	-	610/1220	3.6/7.2
Width can be customized: 610 mm – 1500 mm
Note: Specifications can be tailored according to customer requirements.



Product Certificate

Customer visits

Packaging Display

Related Products

FAQ

Q1: Can I get samples? / Are you willing to provide free samples to us?

A1: Of course, SUNTHERM provides free samples, and the shipping cost can be negotiated by both parties. / Of course, we will send free samples for your reference.

Q2: Can I use our own logo or design to make stickers? / Can I request customized shipping marks?

A2: Yes, SUNTHERM has a professional designer team and can design according to your requirements. / Yes, we accept customized shipping marks.

Q3: Are your prices flexible?

A3: Certainly, our pricing is based on order quantity. We're happy to discuss volume discounts for larger purchases.
